Printer Specifications
Resolution
203 dpi/8 dots per mm
Memory
Standard: 4 MB Flash; 8 MB SDRAM
Print Width
4.09"/104 mm
Maximum Print Length
39"/991 mm
Maximum Print Speed
5"/127 mm per second
Media Sensors
Standard: Fixed reflective and transmissive sensors
Media Characteristics
Maximum Label and Liner Length
Maximum non-continuous: 39"/991 mm
Maximum Label and Liner Width
0.75"/19 mm - 4.25"/108 mm
Maximum Media Roll Size
5"/127 mm O.D.
Media Thickness
0.003"/0.08 mm to 0.0075"/0.19 mm
Media Types
Roll-fed or fan-fed, die-cut or continuous direct thermal labels with or without black line, tag stock, continuous receipt paper, wristbands
Ribbon Characteristics
- Outside diameter: 1.36"/35 mm
- Standard length: 244'/74 m
- Ratio: 1:1 media to roll to ribbon
- Width: 1.33"/33.8 mm to 4.3"/109.2 mm
- Core inner diameter: 0.5"/12.7 mm
Communication and Interface Capabilities
- USB V1.1, bi-directional
- Ethernet—10/100 internal
- Core inner diameter: 0.5"/12.7 mm
Dimensions
6.75"/171 mm. L x 6.0"/152 mm. W x 8.25"/210 mm. H
Product Weight
3 lbs/1.4 kg
